Mini Liposome Extruder

Convenient

• Prepare small or large, unilamellar vesicles (SUVs or GUVs) by extrusion in an easy, rapid, & efficient manner

• Design allows for the rapid cleaning of all wetted parts, reducing down-time between production of  vesicles from batch to batch.

• Generate uniform populations of unilamellar vesicles without the use of solvents or detergents

• Vesicle size readily controlled by polycarbonate membrane selection

Flexible

• Optional heating block allows the extrusion of vesicles at elevated temperatures, which is critical for the successful production of vesicles from phospholipids with a phase transition temperature above room temperature

• Generate unilamellar vesicles ranging from 30nm – 1µm when assembled with appropriate polycarbonate membrane

• Useful for a wide variety of lipid compositions

• Interchangeable with 250µL & 1000µL syringes

Affordable

• Available for a fraction of the cost of a larger extruder

• All replacement parts and accessories are available

• Complete set includes:

Mini-extruder

Heating block/holder

2-Gas Tight Syringes (1000uL)

2 O-rings

100 polycarbonate membranes (0.1µm)

100 Polyester filter supports

Reliable

The particle size distribution of unilamellar vesicles prepared by extrusion is a function of the number of passes through the extruder membrane.

Hydrated lipid films will initially form large, multi-lamellar vesicles. After the initial pass through a membrane, the particle size distribution will tend towards bimodal.

After sufficient passes through the membrane, a unimodal, normal distribution is obtained. A minimum of eleven passes through the extruder membrane is recommended for most lipids.

Placing the heating block assembly on a hot plate achieves rapid temperature control for lipids that have transition temperatures above room temperature.
